Products specifications Report Issue?

Category RF and Wireless - RF Misc ICs and Modules
Mfr NXP USA Inc.
Package Tape & Reel
Function Advanced Doherty Alignment Module
Frequency 3.4GHz ~ 3.8GHz
RF Type General Purpose
Mounting Type Surface Mount
Package / Case 32-VFQFN Exposed Pad
Supplier Device Package 32-QFN (6x6)
Base Product Number MMDS36254
Standard Package 1,000
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1346018-MMDS36254HT1
Ultra Librarian 3D Model Ultra Librarian MMDS36254HT1 CAD Model

Description

The NXP MMDS36254HT1 is a state-of-the-art RF power LDMOS transistor designed for high-efficiency, high-gain, and wideband capabilities, which makes it ideal for broadcast and industrial applications. This device is part of NXP's advanced LDMOS technology that focuses on delivering superior performance in RF power amplification.

With its excellent thermal stability and ruggedness, the MMDS36254HT1 is capable of withstanding extreme operating conditions, making it a reliable choice for applications requiring high power density and longevity. It operates at a frequency range of up to 600 MHz, providing a broad spectrum of use cases from digital broadcasting to aerospace and defense systems.

Key Features:

  • High Efficiency: The MMDS36254HT1 offers an impressive efficiency that minimizes power loss and heat dissipation, contributing to a greener and more cost-effective solution.
  • Wide Frequency Range: This transistor is designed to work efficiently across a wide frequency band, ensuring versatility and adaptability to various RF applications.
  • High Gain: It provides high gain levels, which translates to improved signal strength and quality, enhancing the overall performance of the RF system.
  • Robustness: Built with ruggedness in mind, the MMDS36254HT1 can endure high voltage standing wave ratios (VSWR), making it resilient in the face of mismatches and operational stress.
  • Thermal Performance: The device is engineered with an excellent thermal path, ensuring heat is effectively dissipated, thus maintaining performance and reliability over time.

Applications:

  • Industrial, Scientific, and Medical (ISM) Band Applications
  • RF Energy Applications
  • Broadcast Transmitters
  • Aerospace and Defense Systems
  • High-Power Amplifiers

The NXP MMDS36254HT1 is a testament to NXP's commitment to providing cutting-edge technology for RF power amplification. Its combination of efficiency, performance, and durability makes it a top choice for designers and engineers looking to push the boundaries of RF application capabilities.
