Product Overview: MC07XSC200EK

The MC07XSC200EK is a cutting-edge power system basis chip (SBC) from the renowned semiconductor manufacturer, NXP Semiconductors. Designed to cater to the demanding requirements of automotive control units, this product integrates multiple features into a single, compact package, making it an efficient solution for power management and communication within vehicle systems.

Key Features

• Integrated Power Management: The MC07XSC200EK offers a range of power management capabilities including a 5V/200mA low dropout regulator, a watchdog timer for system reliability, and a high-speed CAN transceiver, ensuring robust communication in automotive environments.
• Advanced Safety: With an emphasis on safety, this SBC features fail-safe outputs, thermal protection, and a dedicated safe mode to protect against system failures, making it ideal for safety-critical applications.
• Enhanced Diagnostics: Equipped with comprehensive diagnostic functions, the chip facilitates the monitoring of system parameters, helping to preemptively identify and rectify potential issues.

Applications

The MC07XSC200EK is versatile in its applications, suitable for a variety of automotive systems including:

• Engine Control Units (ECUs)
• Transmission Control Modules
• Body Control Modules
• Gateway Systems

Technical Specifications

The device boasts a wide operating voltage range, high-speed communication interfaces, and a robust package that can withstand harsh automotive conditions. Its technical specifications include:

• Voltage range: 6V to 27V
• 5V voltage regulator with a 200mA current capability
• High-speed CAN interface (ISO 11898-2)
• Package: 24-lead SOIC

Quality and Reliability

NXP's commitment to quality and reliability is evident in the MC07XSC200EK, which is designed to meet the stringent requirements of the automotive industry. The product is manufactured with high-quality materials and undergoes rigorous testing to ensure it performs reliably over its intended lifespan.
