NXP LPC2368FBD100,551 Microcontroller

The LPC2368FBD100,551 is a high-performance microcontroller unit (MCU) from NXP's LPC23xx series, designed for embedded applications that require efficient processing, a variety of communication interfaces, and low power consumption. This powerful MCU is built around a 16/32-bit ARM7TDMI-S CPU core with a wide range of integrated peripherals, making it an ideal choice for industrial control, medical systems, protocol converters, and many other embedded systems.

Key Features

• Core: ARM7TDMI-S processor, running at up to 72 MHz.
• Memory: 512 KB on-chip flash memory with In-System Programming (ISP) and In-Application Programming (IAP) capabilities, 58 KB of RAM, and 8 KB of EEPROM.
• Debugging: JTAG and serial wire debug, as well as embedded trace support for advanced debugging.
• Communication Interfaces: Multiple serial communication interfaces including USB 2.0 Full Speed device, 3 UARTs, 3 I2C buses, SPI, and SSP with buffering and variable data length capabilities.
• Timers: Four 32-bit timers with capture/compare capabilities and a PWM unit for accurate pulse generation.
• Analog to Digital Converter (ADC): 10-bit ADC with 8 channels and a conversion time as low as 2.44 µs.
• Power Management: Integrated power control for reduced power modes and enhanced power-saving features.
• Packaging: LQFP-100 package, which provides a compact footprint for space-constrained applications.
• Operating Voltage: 3.3V power supply with 5V tolerant I/O pads.

Applications

The LPC2368FBD100,551 MCU is highly versatile and can be used in a variety of applications, including but not limited to:

• Industrial control systems
• Medical instrumentation
• Networking systems
• Protocol conversion
• Automotive and telematics
• Alarm systems
• POS terminals

With its robust set of features and capabilities, the LPC2368FBD100,551 from NXP stands out as a reliable and efficient solution for complex and demanding embedded tasks. Whether you're designing a new system or upgrading an existing one, this MCU provides the performance, versatility, and reliability required to meet the needs of your application.
