The NXP LPC1113FBD48/302 is a highly capable microcontroller that forms part of the widely acclaimed LPC1100 family. Designed with a focus on high performance and low power consumption, this device is ideal for a wide range of applications in the industrial, consumer, and computing markets.

Key Features

• Core: At the heart of the LPC1113FBD48/302 is a powerful ARM Cortex-M0 processor, which operates at frequencies of up to 50 MHz, providing users with a perfect balance between processing power and energy efficiency.
• Memory: This microcontroller is equipped with 24 KB of on-chip flash memory and 8 KB of SRAM, ensuring ample space for complex programs and real-time data processing.
• I/O Options: It offers a versatile set of I/O options including 36 GPIO pins, which can be used for a variety of peripherals and custom functions to meet the needs of diverse applications.
• Serial Communication: The device supports multiple serial communication interfaces, including I2C, SPI, and UART, allowing for easy integration into a communication network and facilitating data exchange with other devices.

Advanced Peripherals

The LPC1113FBD48/302 also boasts a range of integrated peripherals. These include an 8-channel 10-bit ADC for analog signal processing, a 32-bit timer, and multiple 16-bit timers, which can be used for precise event timing and wave generation. Additionally, the microcontroller includes a Watchdog Timer for system reliability and a SSP/SPI interface for enhanced connectivity options.

Energy Efficiency

NXP has engineered the LPC1113FBD48/302 with energy efficiency in mind. It features an ultra-low power mode and a power-on reset (POR) and brown-out detect circuitry to ensure reliable operation even in unstable power conditions. This makes the microcontroller particularly suitable for battery-powered and portable devices where power conservation is critical.

Package and Support

The microcontroller comes in a compact 48-pin LQFP package, which is conducive to space-constrained applications. NXP provides comprehensive development support for the LPC1113FBD48/302, including software libraries, development tools, and a robust community forum for troubleshooting and knowledge sharing.
