Products specifications

Category Discrete Semiconductor Products
Family Diodes - Rectifiers - Arrays
Manufacturer NXP
Packaging Tube
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) (per Diode) 20A
Voltage - Forward (Vf) (Max) @ If 1.15V @ 20A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 25ns
Current - Reverse Leakage @ Vr 30μA @ 100V
Mounting Style Through Hole
Package TO-220-3
Manufacturer Device Package TO-220AB
Win Source Part Number 201716-BYV32E-100
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BYV32E-100 CAD Model

Description

The BYV32E-100, manufactured by NXP Semiconductors, is a robust dual ultrafast rectifier designed for applications requiring efficient and reliable high-speed switching. This powerful electronic component is engineered to deliver high performance in a compact package, making it an ideal choice for space-constrained environments.

Key Features:

  • High Reverse Voltage Capability: With a reverse voltage rating of 100V, the BYV32E-100 is suitable for high-voltage applications, providing excellent power handling capabilities.
  • Fast Switching Speed: The device features an ultrafast recovery time, typically less than 35ns, which is essential for high-efficiency power supplies and minimizes losses during the switching process.
  • Low Forward Voltage Drop: The low forward voltage drop helps to reduce power losses and improve overall efficiency, making it an energy-saving solution for power management.
  • Dual Diode Configuration: This rectifier contains two diodes in a common cathode arrangement, allowing for simplified circuit design and a reduction in component count.
  • High Surge Current Capability: It can handle high surge currents, ensuring reliability and robustness during transient conditions.
  • Robust Package: Enclosed in a SOT404 package, the BYV32E-100 is designed for rugged operation and is capable of withstanding harsh environmental conditions.

Applications:

The BYV32E-100 is versatile and can be used in a variety of applications, including:

  • Switch-mode power supplies (SMPS)
  • Power factor correction (PFC) circuits
  • Freewheeling diodes in converters and motor control circuits
  • Energy storage systems
  • High-frequency rectification

Quality and Reliability:

NXP Semiconductors is known for its commitment to quality, and the BYV32E-100 is no exception. It is produced with high manufacturing standards, ensuring consistent performance and reliability for critical applications.
