Manufacturer NXP
Win Source Part Number 039694-BT137S-800E
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BT137S-800E CAD Model

Description

The BT137S-800E is a high-performance, sensitive gate Triac manufactured by NXP Semiconductors, designed for use in applications requiring direct interfacing to microcontrollers, logic integrated circuits, and other low power gate trigger circuits. This device is particularly well-suited for AC switching and phase control applications such as fan speed and temperature modulation, lighting controls, and static switching relays.

Key Features

  • Blocking Voltage: The BT137S-800E boasts a maximum repetitive peak off-state voltage (VDRM) of 800V, making it suitable for operations in a wide range of mains voltages.
  • On-state Current: With an RMS on-state current (IT(RMS)) of 8A, it can handle significant power, suitable for controlling moderately high loads.
  • Gate Sensitivity: The device features a sensitive gate that requires only a small gate current to trigger, facilitating direct interfacing with digital circuits without the need for additional amplification.
  • High Surge Current Capability: It has a non-repetitive peak on-state surge current (ITSM) of up to 80A, which allows it to handle high inrush currents typical in AC loads.
  • Package: The BT137S-800E comes in a D2PAK surface-mount package, which is ideal for compact designs and automated PCB assembly processes.

Applications

The versatility of the BT137S-800E allows it to be integrated into a wide array of applications. These include, but are not limited to:

  • Home appliances (e.g., washing machines, vacuum cleaners, and kitchen appliances)
  • Light dimmers and X10 home automation systems
  • Motor control circuits for fans, blowers, and pumps
  • Power tools and office equipment
  • Industrial process control units

Environmental and Quality Standards

The NXP BT137S-800E is compliant with international environmental and quality standards, including RoHS and the latest industrial standards for quality assurance. This ensures that the product is not only durable and reliable but also environmentally friendly.
