Product Overview: 74HC4514D from NXP

The 74HC4514D is a high-speed Si-gate CMOS device and is pin compatible with low-power Schottky TTL (LSTTL). Manufactured by NXP Semiconductors, it is part of the 74HC family, which is renowned for its robust performance and compatibility with a wide range of applications in the electronics industry.

Key Features

• Logic Type: 4-to-16 Line Decoder/Demultiplexer with input latches.
• Package: The device comes in a slim SOIC 24-pin package, providing a compact footprint suitable for space-constrained applications.
• Supply Voltage Range: Operates with a supply voltage range from 2.0V to 6.0V, accommodating various logic level requirements and ensuring compatibility with both TTL and CMOS logic levels.
• High-Speed Operation: Features a typical propagation delay of only 16ns, enabling high-speed performance critical for modern digital systems.
• Current Capability: Capable of driving 15 LSTTL loads, allowing for direct interfacing with numerous standard logic families.
• ESD Protection: Includes protection against electrostatic discharge, enhancing the durability and longevity of the device.

Applications

The 74HC4514D is versatile and can be used in a variety of applications such as:

• Memory decoding or data routing
• Control systems
• Computer systems
• Instrumentation and measurement systems

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The 74HC4514D is no exception, as it undergoes rigorous testing and quality control measures to ensure reliable performance in a range of environmental conditions.

Environmental Compliance

Adhering to environmental standards, the 74HC4514D is available in a lead-free package, making it suitable for eco-friendly manufacturing and RoHS compliant applications.

With its combination of high-speed operation, compatibility with multiple logic levels, and robust environmental compliance, the 74HC4514D is an excellent choice for designers looking to implement a reliable decoding or demultiplexing solution in their digital systems.
