UF5407 Jinan Gude Electronic Device
Same model may have multiple batches, images only for reference.

UF5407

Part No UF5407
Manufacturer NTE
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 800V 3A DO201AD / Diode 800 V 3A Through Hole DO-201AD
Datasheet
UF5407 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 800 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 1.7 V @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 75 ns
Current - Reverse Leakage @ Vr 10 µA @ 800 V
Capacitance @ Vr, F 36pF @ 4V, 1MHz
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Supplier Device Package DO-201AD
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 694230-UF5407
Ultra Librarian 3D Model Ultra Librarian UF5407 CAD Model

Description

The 694230-UF5407 is a fast recovery rectifier diode designed for various electronic applications.

  • Maximum Reverse Voltage: 800 V
  • Average Rectified Current: 3A
  • Forward Voltage Drop: 1.7 V @ 3 A
  • Reverse Recovery Time: 75 ns
  • Reverse Leakage Current: 10 μA @ 800 V
  • Capacitance: 36 pF @ 4V and 1 MHz
