Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr NTE
Series RGP15
Package Bag
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 400 V
Current - Average Rectified (Io) 1.5A
Voltage - Forward (Vf) (Max) @ If 1.3 V @ 1.5 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 150 ns
Current - Reverse Leakage @ Vr 5 µA @ 400 V
Capacitance @ Vr, F 25pF @ 4V, 1MHz
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Supplier Device Package DO-201AD
Standard Package 1 pcs
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 660225-RGP15G
Ultra Librarian 3D Model Ultra Librarian RGP15G CAD Model

Description

The 660225-RGP15G is a single rectifier diode that belongs to the Discrete Semiconductor Products category.

  • Application: Designed for use in various electronic circuits that require rectification of AC signals.
  • Series: Part of the RGP15 series, known for its fast recovery time and high current capability.
  • Voltage Reverse (Vr): rated @ 400 V, allowing it to handle higher voltage levels.
  • Average Rectified Current (Io): 1.5A, can handle moderate current levels.
  • Voltage Forward (Vf) @ Current of 1.5 A: 1.3 V, ensuring low voltage drop during operation.
  • Reverse Recovery Time (trr): 150 ns, providing fast switching characteristics.
  • Mounting Type: through-hole mounting type
  • Package: DO-201AD axial package.
  • Operating Temperature Range: Specified by the manufacturer.
  • Overall: a reliable rectifier diode that offers fast recovery time and high current capability in electronic circuits.
