NRF24Z1 Nordic Semiconductors
Same model may have multiple batches, images only for reference.

NRF24Z1

Part No NRF24Z1
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description IC RF TXRX ISM>1GHZ 36-VFQFN / IC RF TxRx Only General ISM > 1GHz 2.4GHz 36-VFQFN Exposed Pad
Datasheet
NRF24Z1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Nordic Semiconductors
Package Tray
Product Status Obsolete
Programmable Not Verified
Type TxRx Only
RF Family/Standard General ISM > 1GHZ
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 4Mbps
Power - Output 0dBm
Sensitivity -80dBm
Serial Interfaces I2C, I2S, SPI
Voltage - Supply 2V ~ 3.6V
Current - Receiving 19.5mA ~ 32mA
Current - Transmitting 14mA ~ 18mA
Temperature Range - Operating -20°C ~ 80°C
Mounting Type Surface Mount
Package / Case 36-VFQFN Exposed Pad
Supplier Device Package 36-QFN (6x6)
Standard Package 490 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 748017-NRF24Z1
Ultra Librarian 3D Model Ultra Librarian NRF24Z1 CAD Model

Description

The Nordic Semiconductors 748017-NRF24Z1 is an RF transceiver IC in the RF and wireless category.

  • Type: TxRx only
  • Package: tray
  • Standard Package: 490 pieces
  • Frequency: 2.4GHz
  • Modulation: GFSK
  • Power Output: 0dBm
  • Sensitivity: -80dBm
  • Data Rate: Up to 4Mbps
  • Current - Receiving: 19.5mA to 32mA
  • Current - Transmitting: 14mA to 18mA
  • Voltage - Supply: 2V to 3.6V
  • Mounting Type: Surface Mount
  • Package / Case: 36-VFQFN Exposed Pad
  • Supplier Device Package: 36-QFN (6x6)
  • Operating Temperature: -20°C to 80°C
  • ECCN: EAR99
  • HTSUS Code: 8542.39.0001
  • Status: Obsolete
  • Manufacturer: Nordic Semiconductors
  • MSL Level: 3
  • Shelf Life: 168 hours
  • REACH Status: Unaffected
