SW3006A/UCV

Part No SW3006A/UCV
Manufacturer NKK Switches
Catalog Rocker Switches
Description STD SIZE ROCKER/MDE-HIGH CAP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Mounting Type Panel Mount, Flange
Circuit DPDT
Switch Function On-On
Current Rating (Amps) 20A (AC/DC)
Voltage Rating - AC 125 V
Voltage Rating - DC 30 V
Actuator Type Concave (Standard V)
Color - Actuator/Cap White
Actuator Marking No Marking
Termination Style Solder Lug
Ingress Protection Dust Proof
Temperature Range - Operating -10°C ~ 70°C
Approval Agency CSA, UL
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1559021-SW3006A/UCV
Ultra Librarian 3D Model Ultra Librarian SW3006A/UCV CAD Model
