AS13CV Nihon Kaiheiki Industry Co. Ltd.
Same model may have multiple batches, images only for reference.

AS13CV

Part No AS13CV
Manufacturer NKK Switches
Catalog Slide Switches
Description SWITCH SLIDE SPDT 0.4VA 28V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - Slide Switches
Mfr NKK Switches
Series AS
Package Tray
Product Status Active
Circuit SPDT
Contact Timing Non-Shorting (BBM)
Switch Function On-Off-On
Current Rating (Amps) 0.4VA (AC/DC)
Voltage Rating - AC 28 V
Voltage Rating - DC 28 V
Actuator Type Standard
Actuator Length 3.80mm
Contact Material Phosphor Bronze
Contact Finish Gold
Mounting Type Through Hole, Right Angle, Vertical
Termination Style PC Pin
Features Epoxy Sealed Terminals
Temperature Range - Operating -30°C ~ 85°C
Actuator Material Polyamide (PA), Nylon, Glass Filled
Switch Travel 2.50mm
Mechanical Life 50,000 Cycles
Electrical Life 50,000 Cycles
Operating Force 260gf
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9050
California Prop 65 Warning Information
Win Source Part Number 564571-AS13CV
Ultra Librarian 3D Model Ultra Librarian AS13CV CAD Model

Description

The AS series slide switch is a versatile component designed for various applications.

  • Termination style: PC pin
  • Terminals: epoxy sealed
  • Contact finish: gold
  • Voltage rating: 28 V for both AC and DC applications
  • Standard package: 1 pc
  • Circuit configuration: SPDT
  • Actuator type: standard with a length of 3.80mm
  • Switch travel: 2.50mm
  • Electrical life: 50,000 cycles
  • Mechanical life: 50,000 cycles
  • Mounting type: through-hole, right-angle, and vertical
  • Manufacturer: NKK Switches
