NJM2257M NJR Corporation/NJRC
Same model may have multiple batches, images only for reference.

NJM2257M

Part No NJM2257M
Manufacturer Nisshinbo Micro Devices Inc.
Catalog Linear - Video Processing
Description IC VIDEO SYNC SEPARATOR 16DMP / Video Separator IC 16-DMP Package
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Linear - Video Processing
Mfr Nisshinbo Micro Devices Inc.
Package Tube
Product Status Obsolete
Function Separator
Applications Consumer Video
Mounting Type Surface Mount
Package / Case 16-SOIC (0.209", 5.30mm Width)
Supplier Device Package 16-DMP
Standard Package 50 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 254064-NJM2257M
Ultra Librarian 3D Model Ultra Librarian NJM2257M CAD Model

Description

The NJM2257M is an integrated circuit designed for video processing applications. It is a separator function IC that can be used in consumer video devices.

  • Package Type: 16-SOIC
  • Width: 5.30mm
  • Supplier Device Package: 16-DMP
  • Voltage Supply: Not Specified
  • Mounting Type: Surface Mount
  • Standard Package: 50 pieces
  • Product Status: Obsolete
  • Manufacturer: Nisshinbo Micro Devices Inc.
  • Function: Separator
  • Application: Video Processing
