Same model may have multiple batches, images only for reference.
UCX1H471MNS1MS Nichicon
Same model may have multiple batches, images only for reference.

UCX1H471MNS1MS

Part No UCX1H471MNS1MS
Manufacturer Nichicon
Catalog Aluminum Capacitors
Description CAP ALUM 470UF 20% 50V SMD / 470 µF 50 V Aluminum Electrolytic Capacitors Radial, Can - SMD 70mOhm 2000 Hrs @ 135°C
Datasheet
UCX1H471MNS1MS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr Nichicon
Series UCX
Package Tape & Reel
Product Status Not For New Designs
Capacitance 470 µF
Tolerance ±20%
Voltage - Rated 50 V
ESR (Equivalent Series Resistance) 70mOhm
Lifetime @ Temp. 2000 Hrs @ 135°C
Temperature Range - Operating -40°C ~ 135°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 500 mA @ 120 Hz
Ripple Current @ High Frequency 1 A @ 100 kHz
Lead Spacing -
Size / Dimension 0.630" Dia (16.00mm)
Height - Seated (Max) 0.669" (17.00mm)
Surface Mount Land Size 0.673" L x 0.673" W (17.10mm x 17.10mm)
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1360302-UCX1H471MNS1MS
Ultra Librarian 3D Model Ultra Librarian UCX1H471MNS1MS CAD Model

Description

The UCX1H471MNS1MS is a radial, surface mount aluminum electrolytic capacitor from Nichicon.

  • Series: UCX
  • Status: Not Recommended for New Designs
  • Capacitance: 470μF
  • Voltage Rating: 50V
  • Temperature Range: -40°C to 135°C
  • Lifetime: 2000 hours @ 135°C
  • Size: 0.630" (16.00mm) diameter and 0.669" (17.00mm) height
  • Equivalent Series Resistance (ESR): 70mOhm
  • Ripple Current (Low Frequency): 500mA @ 120Hz
  • Ripple Current (High Frequency): 1A @ 100kHz
  • Polarized: Yes
  • Mounting Type: Surface Mount
  • REACH: Complies
  • ECCN: EAR99
