The NPIM75B4R7MTRF is a power inductor manufactured by NIC-Components Corp. This inductor is designed for use in DC-DC converters and other power supply applications. It features a shielded construction for low EMI and a compact size for space-constrained applications.

Applications:

• DC-DC Converters
• Power Supplies
• Buck Converters
• Boost Converters
• Portable Electronics

Features:

• Shielded Construction
• Compact Size: 7.3 x 7.3 x 4.5 mm
• High Saturation Current
• Surface Mount Technology (SMT)
• Operating Temperature Range: -40°C to +125°C
• Ferrite Core Material

Benefits:

• Reduced Electromagnetic Interference (EMI) due to shielded construction, improving the performance of sensitive electronic circuits.
• Space-saving design allows for smaller and more compact electronic devices.
• Stable operation under high current conditions due to high saturation current.
• Simplified manufacturing process through the use of standard surface mount technology.
• Reliable performance across a wide range of operating temperatures, suitable for various environmental conditions.

Technical Specifications:

Inductance: 4.7 µH
Tolerance: ±20%
Saturation Current: 2.0 A
DC Resistance (DCR): 85 mΩ (typical)
Self-Resonant Frequency (SRF): 60 MHz (typical)
Operating Temperature: -40°C to +125°C
Core Material: Ferrite
Termination: Tin Plating

The NPIM75B4R7MTRF inductor provides an efficient and reliable solution for power management in various electronic devices. Its shielded design effectively minimizes electromagnetic interference, while its compact size makes it suitable for applications where space is limited. The high saturation current ensures stable operation even under demanding conditions. This inductor is an excellent choice for designers seeking a high-performance, space-saving component for their power supply circuits.
