PMEG4020EPK,315

Name: PMEG4020EPK,315
Brand: Nexperia USA Inc.
SKU: 792427
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PMEG4020EPK,315
Manufacturer	Nexperia USA Inc.
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 40V 2A 2DFN / Rectifier Diode Schottky 40V 2A 4ns Automotive 2-Pin DFN-D T/R
Datasheet	PMEG4020EPK,315 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Nexperia USA Inc.
Packaging	Reel package
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Maximum)	40V
Current - Average Rectified (Io)	2A
Voltage - Forward (Vf) (Maximum) @ If	660mV @ 2A
Speed	Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr)	4ns
Current - Reverse Leakage @ Vr	5μA @ 10V
Capacitance @ Vr, F	90pF @ 1V, 1MHz
Mounting	SMD
Package	2-XDFN
Manufacturer Package	DFN1608D-2
Operating Temperature - Junction	150°C (Maximum)
Win Source Part Number	792427-PMEG4020EPK,315
Popularity	Medium
Supply and Demand Status	Limited
Family Name	PMEG4020EPK
Introduction Date	April 25, 2012
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian PMEG4020EPK,315 CAD Model

Alternative Products

Description

The PMEG4020EPK Schottky diode is manufactured by Nexperia USA Inc.

Type: Fast Recovery Diode
Current (Io): 200mA
Maximum Current: 2A
Reverse Recovery Time: 4ns
Package: 2-XDFN
Mounting: SMD
Capacitance: 90pF @ 1V, 1MHz
Operating Temperature: Up to 150°C
Compliance: Halogen-free
Manufacturer Location: China
Estimated EOL Date: 2026
