PHDMI2FR4Z

Name: PHDMI2FR4Z
Brand: Nexperia USA Inc.
SKU: 1362424
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PHDMI2FR4Z
Manufacturer	Nexperia USA Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 3VC DFN2510A-10 / 3V (Typ) Clamp 7A (8/20µs) Ipp Tvs Diode Surface Mount DFN2510A-10
Datasheet	PHDMI2FR4Z Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Nexperia USA Inc.
Series	-
Package	Tape & Reel
Product Status	Active
Type	Steering (Rail to Rail)
Unidirectional Channels	4
Voltage - Reverse Standoff (Typ)	-
Voltage - Breakdown (Min)	6V
Voltage - Clamping (Max) @ Ipp	3V (Typ)
Current - Peak Pulse (10/1000µs)	7A (8/20µs)
Power - Peak Pulse	-
Power Line Protection	No
Applications	General Purpose
Capacitance @ Frequency	0.34pF @ 1MHz
Temperature Range - Operating	-40°C ~ 85°C (TA)
Mounting Type	Surface Mount
Package / Case	10-XFDFN
Supplier Device Package	DFN2510A-10
Base Product Number	PHDMI2
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	1362424-PHDMI2FR4Z
Ultra Librarian 3D Model	Ultra Librarian PHDMI2FR4Z CAD Model

Alternative Products

Description

The 1362424-PHDMI2FR4Z is a circuit protection component from Nexperia USA Inc.

Type: Steering (Rail to Rail)
Component Type: Transient voltage suppressor (TVS) diode
Operating Temperature: -40°C to 85°C
Package: 10-XFDFN
Mounting Type: Surface Mount
Application: General Purpose
Voltage Breakdown: 6V
Clamping Voltage: 3V (typical) @ a peak pulse current of 7A (10/1000µs)
Number of Channels: 4 Unidirectional
Capacitance: 0.34pF @ 1MHz frequency
REACH: Unaffected
ECCN: EAR99
