PESD5V0F1BL,315

Name: PESD5V0F1BL,315
Brand: Nexperia USA Inc.
SKU: 504011
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PESD5V0F1BL,315
Manufacturer	Nexperia USA Inc.
Catalog	TVS - Diodes
Description	ESD Suppressor Diode TVS Bi-Dir 5.5V Automotive 2-Pin DFN T/R / TVS DIODE 5.5VWM 15VC SOD882
Datasheet	PESD5V0F1BL,315 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Nexperia USA Inc.
Packaging	Reel - TR
Status	Active
Type	Zener
Bidirectional Channels	1
STAND-OFF Voltage (Vwm)	5.5V (Max)
Minimum Breakdown Voltage	6V
Max Clamping Voltage	15V
Peak Pulse Current(Ippm)	2.5A (8/20μs)
Applications	Automotive
Capacitance @ Frequency	0.4pF @ 1MHz
Temperature Range - Operating	-40°C to 125°C (TA)
Mounting	SMD (SMT)
Case / Package	SOD-882
Win Source Part Number	1087573-PESD5V0F1BL,315
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	PESD5V0F1BL
Introduction Date	October 02, 2009
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2026
Ultra Librarian 3D Model	Ultra Librarian PESD5V0F1BL,315 CAD Model

Alternative Products

Description

The PESD5V0F1BL,315 is a Zener type electronic component manufactured by Nexperia USA Inc.

Channel: Bidirectional
Capacitance: 0.4pF @ 1MHz
Packaging: SMD (SMT)
Family: PESD5V0F1BL
Application: Circuit protection in automotive applications
STAND-OFF Voltage (Vwm): 5.5V (Max)
Breakdown Voltage: 6V (Min)
Clamping Voltage: 15V (Max)
Peak Pulse Current(Ippm): 2.5A (8/20μs)
Halogen-Free Standards: Compliant
Usage: Common-used part
