Same model may have multiple batches, images only for reference.
74HCT4052BQ,115 Nexperia USA Inc. 74HCT4052BQ,115 label picture 2 74HCT4052BQ,115 real image 74HCT4052BQ,115 label picture 1
74HCT4052BQ,115 Nexperia USA Inc. 74HCT4052BQ,115 label picture 2 74HCT4052BQ,115 real image 74HCT4052BQ,115 label picture 1
Same model may have multiple batches, images only for reference.

74HCT4052BQ,115

Part No 74HCT4052BQ,115
Manufacturer Nexperia USA Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MUX/DEMUX DUAL 4X1 16DHVQFN
Datasheet
74HCT4052BQ,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Switch Circuit SP4T
Number of Circuits 2
Max On Resistance 150 Ohm
Channel-to-Channel Matching (ΔRon) 6 Ohm
Single Supply Voltage (V+) 4.5 V to 5.5 V
Dual Supply Voltage(V±) ±1 V to 5 V
Max Switch Time (Ton,Toff) 60ns, 48ns
-3db Bandwidth 180MHz
Channel Capacitance(CS off, CD off) 3.5pF
Max Leakage Current (IS off) 2μA
Crosstalk -60dB @ 1MHz
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 16-DHVQFN (2.5x3.5)
Win Source Part Number 1008787-74HCT4052BQ,115
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 74HCT4052BQ,115 CAD Model

Description

The Nexperia USA Inc. 74HCT4052BQ,115 is an integrated circuit with 2 circuits and SP4T switch circuit.

  • -3db Bandwidth: 180MHz
  • Channel-to-channel Matching (ΔRon): 6 Ohm
  • Temperature Range: -40°C to 125°C (TA)
  • Max On Resistance: 150 Ohm
  • Package: 16-DHVQFN (2.5x3.5)
  • Single Supply Voltage: 4.5 V to 5.5 V
  • Dual Supply Voltage: ±1 V to 5 V
  • Max Switch Time (Ton,Toff): 60ns, 48ns
  • Channel Capacitance (CS off, CD off): 3.5pF
  • Max Leakage Current (IS off): 2μA
  • Suitable for: use in integrated circuits
