NMH0512SC Real Image NMH0512SC Real Image1 NMH0512SC Real Image2
Same model may have multiple batches, images only for reference.
NMH0512SC Real Image NMH0512SC Real Image1 NMH0512SC Real Image2
NMH0512SC Real Image NMH0512SC Real Image1 NMH0512SC Real Image2
Same model may have multiple batches, images only for reference.

NMH0512SC

Part No NMH0512SC
Manufacturer Murata Power Solutions Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-12V 2W
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Murata Power Solutions Inc.
Series NMH (2W)
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 83mA, 83mA
Power (Watts) 2 W
Voltage - Isolation 1 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 85°C
Efficiency 82%
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Size / Dimension 0.77" L x 0.30" W x 0.40" H (19.6mm x 7.6mm x 10.2mm)
Base Product Number NMH05
Standard Package 25 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 649153-NMH0512SC
Ultra Librarian 3D Model Ultra Librarian NMH0512SC CAD Model

Description

The NMH0512SC is a 2W isolated module DC-DC converter from Murata Power Solutions Inc.

  • Series: NMH
  • Application: Power Supplies, Board Mount
  • Voltage - Isolation: 1 kV
  • Number of Outputs: 2
  • Current - Output: 83mA
  • Voltage - Input: 4.5V ~ 5.5V
  • Voltage - Output: 12V, -12V
  • Efficiency: 82 %
  • Package: Tube
  • Size: 0.77" L x 0.30" W x 0.40" H
  • Applications: ITE (Commercial)
  • Operating Temperature: -40°C ~ 85°C
  • Status: Active
