56300C Real Image
Same model may have multiple batches, images only for reference.

56300C

Part No 56300C
Manufacturer Murata Power Solutions Inc.
Catalog Current Sense Transformers
Description CURR SENSE XFMR 10A T/H / 10 A Current Sense Transformer 20kHz ~ 200kHz 5.73mOhm Primary, 8.59mOhm Secondary Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Current Sense Transformers
Manufacturer Murata Power Solutions Inc.
Packaging Box
Frequency Range 20kHz ~ 200kHz
Type Non-Invasive (Solid Core)
Current Rating (Amps) 10 A
DC Resistance (DCR) 5.73mOhm Primary, 8.59mOhm Secondary
Mounting Through Hole
Size / Dimension 0.661" L x 0.350" W (16.79mm x 8.89mm)
Height - Seated (Max) 0.795" (20.19mm)
Termination Style PC Pin
Weight 0.013 lb (5.70 g)
Base Product Number 56
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Other Part Number 811-3110,56300C-ND
Standard Package 25
Win Source Part Number 1329801-56300C
Ultra Librarian 3D Model Ultra Librarian 56300C CAD Model

Description

The 1329801-56300C is a high-quality current sense transformer manufactured by Murata Power Solutions Inc.

  • Type: Non-Invasive (Solid Core)
  • Termination Style: PC Pin
  • Size: 0.661" L x 0.350" W
  • Frequency Range: 20kHz to 200kHz
  • Current Rating: 10A
  • ROHS3 Compliant: Yes
  • REACH: Unaffected
