The PKLCS1212E-4001 is a series of common mode chokes manufactured by Murata Electronics North America, designed for noise suppression in various electronic circuits. These chokes are particularly effective at attenuating common mode noise, which can be a significant source of interference in sensitive applications. They are constructed with a bifilar winding on a ferrite core, providing high impedance to common mode currents while having minimal impact on differential mode signals.

Applications:

• USB interfaces
• CAN bus systems
• LVDS circuits
• Power lines
• Signal lines

Features:

• High common mode impedance for effective noise suppression
• Low differential mode impedance to minimize signal distortion
• Compact size for space-constrained applications
• Surface mount technology (SMT) for easy assembly
• RoHS compliant
• Excellent temperature stability

Benefits:

• Reduced electromagnetic interference (EMI)
• Improved signal integrity
• Enhanced system reliability
• Compliance with regulatory standards
• Easy integration into existing designs
• Consistent performance across a wide temperature range

Technical Specifications:

The PKLCS1212E-4001 common mode choke typically features a high common mode impedance at specific frequencies (e.g., 100 MHz) to effectively attenuate noise. Its differential mode impedance is kept low to minimize signal degradation. The device is designed for surface mount assembly and is available in tape and reel packaging. Key specifications include the rated voltage, rated current, and operating temperature range. The core material is selected to optimize performance across the intended frequency range. Precise details of the common mode impedance characteristics and frequency response can be found on the Murata datasheet. It's crucial to choose the appropriate choke based on the frequency range and amplitude of the expected common mode noise.
