MP3398AGF-Z

Name: MP3398AGF-Z
Brand: Monolithic Power Systems Inc.
SKU: 755115
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	MP3398AGF-Z
Manufacturer	Monolithic Power Systems Inc.
Catalog	PMIC - LED Drivers
Description	IC LED DRVR CTRLR PWM 16TSSOP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Package	Tape & Reel (TR);Cut Tape (CT);
Product Status	Active
Type	DC DC Controller
Topology	Step-Up (Boost)
Internal Switch(s)	No
Number of Outputs	4
Voltage - Supply (Min)	5V
Voltage - Supply (Max)	28V
Current - Output / Channel	350mA
Frequency	540kHz
Dimming	Analog, PWM
Applications	Backlight
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package	16-TSSOP-EP
Ultra Librarian 3D Model	Ultra Librarian MP3398AGF-Z CAD Model

Description

The Monolithic Power Systems Inc. DC DC Controller MP3398AGF-Z is a step-up (boost) topology controller designed for backlight applications manufactured by Monolithic Power Systems Inc.

Frequency: 540kHz
Current Output Per Channel: 350mA
Package: 16-TSSOP-EP
Operating Temperature Range: -40°C to 125°C
Dimming: Analog and PWM
Outputs: Four
Input Voltage Range: 5V to 28V
Suitable for: a wide range of applications.
Supply and Demand Status: balanced
Manufacturer Pack Quantity: 1
