90131-0768 Real Image
Same model may have multiple batches, images only for reference.

90131-0768

Part No 90131-0768
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 16 POS 2.54mm Solder ST Thru-Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Brass
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin SG
Current Rating 3 A
Gender Male
Housing Color Black
Housing Material Polyester
Insulation Resistance 5 GΩ
Lead Free Yes
Lead Pitch 2.54 mm
Maximum Operating Temperature 125 °C
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 16
Number of Contacts 16
Number of Poles 16
Number of Positions 16
Number of Rows 2
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Working Voltage 350 V
Win Source Part Number 1018178-90131-0768
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90131-0768 CAD Model

Description

The Molex, LLC 1018178-90131-0768 is a 16-position male connector with a pitch of 2.54 mm.

  • Positions: 16
  • Connector Type: Male
  • Pitch: 2.54 mm
  • Current Rating: 3 A
  • Voltage Rating: 350 V
  • Contact Material: Brass
  • Contact Plating: Gold
  • Housing Material: Polyester
  • Housing Color: Black
  • Contact Resistance: 20 mΩ
  • Insulation Resistance: 5 GΩ
  • RoHS Compliant: Yes
  • Lead-Free: Yes
  • Operating Temperature: -55 °C to 125 °C
  • Mounting Type: Through-Hole
  • Suitable for: Circular connectors - housings
