90130-1216 Real Image
Same model may have multiple batches, images only for reference.

90130-1216

Part No 90130-1216
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Connector Accessories Preformed Bridge
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Gender Male
Contact Material Brass, Copper
Contact Mating Length 6.7564 mm
Contact Plating Gold
Contact Resistance 20 mΩ
Country of Origin SK
Current Rating 3 A
Depth 9.75 mm
Gender Male
Glow Wire Compliant Non-compliant
Height 10.9 mm
Housing Color Black
Housing Material Polyester
Insulation Resistance 5 GΩ
Lead Free Yes
Lead Length 2.9 mm
Lead Pitch 2.54 mm
Length 23.04 mm
Material Glass, Polyester
Mating Post Length 6.75 mm
Max Current Rating 3 A
Maximum Operating Temperature 125 °C
Max Voltage Rating (DC) 350.35 kV
Min Operating Temperature -55 °C
Mount Through Hole
Number of Circuits 16
Number of Contacts 16
Number of Pins 16
Number of Poles 16
Number of Positions 16
Number of Rows 2
Orientation Vertical
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Row Spacing 2.54 mm
Termination Solder
Voltage Rating 350 V
Voltage Rating (AC) 350 V
Voltage Rating (DC) 350 V
Working Voltage 350 V
Win Source Part Number 1029137-90130-1216
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90130-1216 CAD Model

Description

This Molex male pin connector is a high-quality component designed for use in electronic devices.

  • Positions: 16
  • Pitch: 2.54 mm
  • Connector Type: Male Pin
  • Rows: 2
  • Row Spacing: 2.54 mm
  • Termination: Solder
  • Contact Mating Length: 6.7564 mm
  • Contact Material: Brass and Copper
  • Voltage Rating: 350 V
  • Current Rating: 3 A
  • Contact Resistance: 20 mΩ
  • Insulation Resistance: 5 GΩ
  • Housing Material: Polyester
  • Housing Color: Black
  • Length: 23.04 mm
  • Height: 10.9 mm
  • Depth: 9.75 mm
  • Working Voltage: 350 V
  • Lead-Free: Yes
  • RoHS Compliant: Yes
  • Mounting Type: Through-Hole
