Same model may have multiple batches, images only for reference.
87438-0743 Real Image
Same model may have multiple batches, images only for reference.

87438-0743

Part No 87438-0743
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Pico-SPOX Surface Mount PCB Header, Right Angle, 7 Contacts, 1 Rows, 1.5mm Pitch
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Beige
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 2.6924 mm
Contact Plating Tin
Contact Resistance 40 mΩ
Country of Origin SG
Current Rating 3 A
Depth 7.75 mm
Gender Male
Housing Color Beige
Housing Material Thermoplastic
Insulation Resistance 1 GΩ
Lead Free Contains Lead
Lead Pitch 1.5 mm
Length 11.8 mm
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 350 V
Min Operating Temperature -55 °C
Mount Surface Mount
Number of Circuits 7
Number of Contacts 7
Number of Positions 7
Number of Rows 1
Orientation Right Angle
Packaging Cut Tape
Pitch 1.5 mm
Plating Tin
RoHS Compliant
Termination Solder
Voltage Rating (DC) 350 V
Win Source Part Number 1004541-87438-0743
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 87438-0743 CAD Model

Description

The 1004541-87438-0743 is a 7-position male pin connector with a 1.5 mm pitch manufactured by Molex.

  • Positions: 7
  • Gender: Male
  • Pitch: 1.5 mm
  • Orientation: Right Angle
  • Termination: Solder
  • Contact Material: Brass
  • Contact Plating: Tin
  • Contact Mating Length: 2.6924 mm
  • Contact Resistance: 40 mΩ
  • Housing Material: Thermoplastic
  • Color: Beige
  • Maximum Operating Temperature: 105 °C
  • Current Rating: 3 A
  • Category: Circular connectors - housings
  • Lead: Leaded
  • RoHS Compliant: Yes
