70551-0042 Real Image
Same model may have multiple batches, images only for reference.

70551-0042

Part No 70551-0042
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Header Connector, pcb Mount, recept, 8 Contacts, pin, 0.1 Pitch, pc Tail Terminal, locking Mech
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Bronze
Contact Plating Gold
Country of Origin US
Current Rating 3 A
ELV Compliant
Flammability Rating UL94 V-0
Glow Wire Compliant Non-compliant
Housing Material Thermoplastic
Material Brass
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Number of Circuits 8
Number of Positions 8
Number of Rows 1
Orientation Right Angle
Pitch 2.54 mm
Plating Tin
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Win Source Part Number 1032664-70551-0042
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 70551-0042 CAD Model

Description

This Molex connector is a right angle connector with 8 contacts and a pitch of 2.54 mm.

  • Voltage Rating: 250 V
  • Current Rating: 3 A
  • Contact Material: bronze
  • Contact Plating: gold
  • Housing Material: thermoplastic
  • Material: brass
  • RoHS Compliant: Yes
  • Maximum Operating Temperature: 105 °C
  • Length: 10.16 mm
  • Suitable for Use: circular connector housings
