Same model may have multiple batches, images only for reference.

67068-8001

Name: 67068-8001
Brand: Molex, LLC
SKU: 1162402
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	67068-8001
Manufacturer	Molex, LLC
Catalog	USB, DVI, HDMI Connectors
Description	Conn USB 2.0 Type B RCP 4 POS 2.5mm Solder RA Thru-Hole 4 Terminal 1 Port USB Tray
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Color	Black
Connector Type	Receptacle, USB
Contact Material	Bronze, Gold
Contact Plating	Gold
Country of Origin	SG
Current Rating	1.5 A
Depth	17 mm
Flammability Rating	UL94 V-0
Gender	Female
Height	11.25 mm
Housing Material	Nylon
Insulation Resistance	1 GΩ
Lead Pitch	2.5 mm
Length	12 mm
Max Operating Temperature	50 °C
Max Voltage Rating (AC)	30 V
Min Operating Temperature	0 °C
Mount	Through Hole
Number of Circuits	4
Number of Contacts	4
Number of Ports	1
Number of Positions	4
Number of Rows	2
Number of Terminals	4
Orientation	Right Angle
Pitch	2.5 mm
Plating	Tin
Radiation Hardening	No
REACH SVHC	Unknown
RoHS	Compliant
Schedule B	8536695050, 8536695050
Termination	Solder
USB Standard	USB 2.0
Voltage Rating	30 V
Win Source Part Number	1162402-67068-8001
Categories	USB,DVI,HDMI Connectors
Manufacturer	Molex, LLC
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian 67068-8001 CAD Model

Description

This 4-position USB receptacle connector from Molex is a reliable and high-performing solution for your USB needs. Molex

Pitch: 2.5mm
Win Source Part Number: 1162402-67068-8001
Contact Material: Bronze with gold plating
Voltage Rating: 30V
Current Rating: 1.5A
Gender: Female
Length: 12mm
Housing Material: Nylon
Category: USB, DVI, HDMI connector
Popularity: Medium
RoHS Compliance: Compliant
Flammability Rating: UL94 V-0
