54363-0289 Real Image
Same model may have multiple batches, images only for reference.

54363-0289

Part No 54363-0289
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description SLIMSTACK Series 0.5mm 20 Way 2 Row Straight PCB Socket Smnt Board to Board
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Bronze
Contact Plating Gold
Country of Origin JP
Current Rating 4 A
ELV Compliant
Gender Receptacle
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Thermoplastic
Lead Pitch 500 µm
Material Bronze
Mount Surface Mount
Number of Circuits 20
Number of Contacts 20
Number of Positions 20
Number of Rows 2
Orientation Vertical
Packaging Cut Tape
Pitch 500 µm
Plating Gold
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Row Spacing 2 mm
Termination Solder
Voltage Rating 50 V
Voltage Rating (AC) 50 V
Win Source Part Number 1039208-54363-0289
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 54363-0289 CAD Model

Description

The 1039208-54363-0289 is a 20-position, 2-row vertical receptacle housing connector designed for circular connectors, manufactured by Molex.

  • Positions: 20
  • Rows: 2
  • Pitch: 500 µm
  • Row Spacing: 2 mm
  • Contact Material: bronze
  • Contact Plating: gold plated
  • Voltage Rating: 50 V
  • Current Rating: 4 A
  • Housing Material: thermoplastic
  • Halogen: low halogen
  • RoHS: compliant
  • ELV: compliant
  • Mounting: surface mount
  • Supply and Demand Status: short supply
