502585-0270 Real Image
Same model may have multiple batches, images only for reference.

502585-0270

Part No 502585-0270
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 1.5 W/B SGL RA REC ASSY2CKTEMBST / Position Connector
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Molex
Series *
Package Bulk
RoHS Status RoHS non-compliant
MSL Level Vendor Undefined
REACH Status REACH info available upon request
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-502585-0270
Standard Package 1
Win Source Part Number 1133631-502585-0270
Ultra Librarian 3D Model Ultra Librarian 502585-0270 CAD Model

Description

This rectangular connector is a female socket designed for use in electronic devices.

  • Series: Molex series
  • Packaging: Bulk
  • RoHS Compliant: Not RoHS compliant
  • ECCN: EAR99
  • Package Standard: 1
  • REACH Status: Information available upon request
  • HTSUS Code: 8536.69.4040
  • Alternative Parts: 502585-0270, 5025850270 and 5025850270
