Same model may have multiple batches, images only for reference.
5019530407 Real Image
Same model may have multiple batches, images only for reference.

5019530407

Part No 5019530407
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 4 POS 1mm Solder RA Side Entry SMD Pico-Clasp™ T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Gender Male
Contact Material Bronze
Contact Plating Tin
Country of Origin JP
Current Rating 1 A
Depth 7.75 mm
Fastening Type Latch, Ramp
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Natural
Housing Material Nylon
Length 6 mm
Max Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 4
Number of Contacts 4
Number of Positions 4
Number of Rows 1
Orientation Right Angle
Pitch 1 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Schedule B 8536694040
Termination Solder
Voltage Rating 50 V
Win Source Part Number 1181159-5019530407
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 5019530407 CAD Model

Description

The 501953-0407 from Molex is a 4-position male pin connector with a pitch of 1mm.

  • Number of Positions: 4
  • Gender: Male
  • Pitch: 1mm
  • Current Rating: 1A
  • Voltage Rating: 50V
  • Color: Natural
  • Housing Material: Nylon
  • Compliance: RoHS
  • Application: Circular Connector
