Part No 501645-3420
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 34 POS 2.5mm Solder ST Thru-Hole Box
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Material Brass
Contact Plating Tin
Country of Origin VN
Current Rating 2 A
Depth 8.2 mm
Fastening Type Latch
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Natural
Housing Material Nylon
Lead Pitch 2 mm
Length 36 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 250 V
Max Voltage Rating (DC) 250.25 kV
Min Operating Temperature -25 °C
Mount Through Hole
Number of Circuits 34
Number of Contacts 34
Number of Positions 34
Number of Rows 2
Orientation Vertical
Pitch 2 mm
Plating Tin
RoHS Compliant
Row Spacing 2.0066 mm
Schedule B 8536694040
Termination Solder
Voltage Rating (AC) 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 967017-501645-3420
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 501645-3420 CAD Model

Description

The 967017-501645-3420 is a male pin circular connector housing manufactured by Molex, LLC.

  • Positions: 34
  • Pitch: 2 mm
  • Color: Natural
  • Material: Nylon
  • Orientation: Vertical
  • Mounting Type: Through Hole
  • Current Rating: 2 A
  • Termination: Solder
  • Length: 36 mm
  • Depth: 8.2 mm
  • Popularity: Low
  • Supply and Demand Status: Short Supply
  • Voltage Rating: 250 V AC/DC
  • Glow Wire Compliant: Non-Compliant
