501645-2820 Real Image
Same model may have multiple batches, images only for reference.

501645-2820

Part No 501645-2820
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 28 POS 2mm Solder ST Top Entry Thru-Hole iGrid™ Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Material Brass
Contact Plating Tin
Country of Origin VN
Current Rating 2 A
Depth 8.2 mm
Fastening Type Latch
Glow Wire Compliant Non-compliant
Housing Color Natural
Housing Material Nylon
Lead Pitch 2 mm
Length 30 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 250 V
Max Voltage Rating (DC) 250.25 kV
Min Operating Temperature -25 °C
Mount Through Hole
Number of Circuits 28
Number of Contacts 28
Number of Positions 28
Number of Rows 2
Orientation Vertical
Pitch 2 mm
Plating Tin
RoHS Compliant
Row Spacing 2.0066 mm
Termination Solder
Voltage Rating (AC) 250 V
Voltage Rating (DC) 250 V
Weight 1.6572 g
Win Source Part Number 999810-501645-2820
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 501645-2820 CAD Model

Description

The Molex 999810-501645-2820 is a circular connector housing with a male pin connector type.

  • Positions: 28
  • Pitch: 2 mm
  • Color: Natural
  • Termination: Solder
  • Contact Plating: Tin
  • Orientation: Vertical
  • RoHS Compliant: Yes
  • Suitable for Applications: Automotive, general purpose, and telecommunications
