The Molex 43650-0609 is a Micro-Fit TPA (Terminal Position Assurance) single-row header designed for wire-to-board connections requiring high reliability and secure terminal retention. This 6-circuit header ensures that the terminals are fully seated and locked in place, preventing accidental disconnections and ensuring consistent electrical performance. Its compact design makes it suitable for applications with limited space, while its robust construction provides long-term durability.

Applications:

• Appliances
• Industrial Equipment
• Automotive
• Medical Devices
• Lighting
• Power Supplies
• Telecommunications

Features:

• Micro-Fit TPA Design: Ensures proper terminal seating and retention.
• Single Row Configuration: Compact design for space-constrained applications.
• 6 Circuits: Accommodates six individual wire connections.
• Through-Hole Termination: Provides a secure and reliable connection to the PCB.
• Positive Locking: Provides a secure connection between the header and receptacle.
• High-Temperature Thermoplastic Housing: Allows for use in reflow soldering processes.
• Polarization Feature: Prevents mismating, ensuring correct connections.

Benefits:

• Increased Reliability: TPA feature minimizes the risk of connection failures due to improperly seated terminals.
• Space Savings: Compact design allows for high-density packaging.
• Simplified Assembly: Through-hole termination simplifies the soldering process.
• Versatile Applications: Suitable for a wide range of applications requiring secure and reliable connections.
• Reduced Downtime: Secure connections minimize the risk of accidental disconnections.
• Error Prevention: Polarization feature prevents incorrect mating.

Additional Details:

The Molex 43650-0609 is designed to mate with Molex Micro-Fit TPA receptacles. It has a current rating of up to 5.0A per circuit. The housing material is high-temperature thermoplastic, compatible with reflow soldering processes. The TPA feature requires a secondary action to fully lock the terminals into the housing. It is RoHS compliant.
