42820-2223 Real Image
Same model may have multiple batches, images only for reference.

42820-2223

Part No 42820-2223
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description MINIFIT SR HDR ASSY 093 CLIP 2 C / Connector Header position
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Molex
Series *
Package Tube
RoHS Status RoHS non-compliant
MSL Level Vendor Undefined
REACH Status REACH info available upon request
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-42820-2223
Standard Package 1
Win Source Part Number 1003281-42820-2223
Ultra Librarian 3D Model Ultra Librarian 42820-2223 CAD Model

Description

The Molex Rectangular Connector is a male pin component with a tube package and a single row.

  • Gender: Male Pin
  • Package: Tube
  • Rows: Single
  • Category: Connectors and Interconnects
  • Pitch: 3 mm
  • Series: *
  • Standard Package: 1
  • Manufacturer: Molex
  • ECCN: EAR99
  • REACH Status: Available Upon Request
  • RoHS Status: Non-Compliant
