34691-0201

Name: 34691-0201
Brand: Molex, LLC
SKU: 1005577
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	34691-0201
Manufacturer	Molex, LLC
Catalog	Circular Connectors - Housings
Description	Conn Shrouded Header HDR 20 POS 2.54mm Solder RA Thru-Hole Tube
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Mounting	SMD (SMT)
Case / Package	0201
Color	Grey
Connector Type	Rectangular
Contact Material	Brass
Contact Plating	Tin
Country of Origin	CN
Current Rating	10 A
Depth	31.89 mm
Gender	Male
Glow Wire Compliant	Non-compliant
Halogen Free	Low Halogen
Height	22.05 mm
Housing Material	Thermoplastic
Maximum Operating Temperature	100 °C
Min Operating Temperature	-40 °C
Mount	Through Hole
Number of Circuits	20
Number of Contacts	20
Number of Positions	20
Number of Rows	2
Orientation	Right Angle
Pitch	2.54 mm
Plating	Tin
REACH SVHC	Unknown
RoHS	Compliant
Schedule B	8536694040, 8536694040
Termination	Through Hole
Voltage Rating	500 V
Voltage Rating (DC)	500 V
Width	34.04 mm
Win Source Part Number	1005577-34691-0201
Categories	Circular Connectors - Housings
Manufacturer	Molex, LLC
Popularity	Low
Supply and Demand Status	Shortage
Ultra Librarian 3D Model	Ultra Librarian 34691-0201 CAD Model

Alternative Products

Description

The Molex, LLC 1005577-34691-0201 is a rectangular connector with 20 positions and 2 rows.

Positions: 20
Rows: 2
Termination: Through-hole
Orientation: Right-angle
Contact Material: Brass
Contact Plating: Tin
Voltage Rating: 500 V
Current Rating: 10 A
Housing Material: Thermoplastic
Low Halogen: Yes
RoHS Compliant: Yes
Width: 34.04 mm
Height: 22.05 mm
Depth: 31.89 mm
Category: Circular connectors - housings
Package: 0201
Supply and Demand Status: Shortage
Popularity: Low
