The 22-28-8034 is a 3-circuit, .093" diameter pin and socket connector housing manufactured by Molex. This housing is designed to provide a robust and reliable connection in various wire-to-wire and wire-to-board applications. It is made from durable nylon material, offering excellent electrical insulation and mechanical strength.

Applications:

• Automotive wiring harnesses: Connecting various electrical components within vehicles.
• Industrial control systems: Providing secure connections in machinery and equipment.
• Consumer electronics: Used in appliances and other electronic devices requiring reliable connections.
• Power supplies: Connecting wires within power supplies and to external devices.
• Lighting systems: Making connections in lighting fixtures and control circuits.

Features:

• Positive latch: Ensures a secure connection and prevents accidental disconnections.
• Durable nylon housing: Provides excellent electrical insulation and mechanical strength.
• Accepts .093" diameter pins and sockets: Allows for a wide range of wire gauges.
• 3-circuit design: Accommodates multiple connections in a compact space.
• Easy to assemble: Simplifies the wiring process and reduces assembly time.

Benefits:

• Reliable connection: The positive latch and durable housing ensure a secure and long-lasting connection.
• Improved safety: The nylon housing provides excellent electrical insulation, reducing the risk of electrical shock.
• Reduced assembly time: The easy-to-assemble design simplifies the wiring process.
• Versatile application: Suitable for a wide range of wire-to-wire and wire-to-board applications.
• Cost-effective: Provides a reliable connection at a competitive price.

Additional Details:

The Molex 22-28-8034 connector housing is designed to be used with Molex .093" series pins and sockets. It has a voltage rating of 600V and a current rating of 19A. The operating temperature range is -40°C to +105°C. This housing is typically used with wire gauges ranging from 18 AWG to 22 AWG. It is RoHS compliant.

Proper crimping tools and techniques are essential to ensure a reliable and secure connection when using this connector housing. Molex offers a range of crimping tools specifically designed for their .093" series connectors.
