Same model may have multiple batches, images only for reference.
22-28-8030 Real Image
Same model may have multiple batches, images only for reference.

22-28-8030

Part No 22-28-8030
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description KK 254 Breakaway Header 90° Surface Mount Compatible 3 Circuits Tin Plating Mating Pin 6.20mm
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Brass
Contact Plating Tin
Country of Origin US
Current Rating 4 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Thermoplastic
Lead Free Contains Lead
Lead Pitch 2.54 mm
Number of Circuits 3
Number of Contacts 3
Number of Positions 3
Number of Rows 1
Orientation Right Angle
Packaging Bulk
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 975286-22-28-8030
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 22-28-8030 CAD Model

Description

The 975286-22-28-8030 is a male circular connector housing manufactured by Molex, LLC.

  • Contact Material: Brass
  • RoHS Compliant: Yes
  • Voltage Rating: 250V
  • Current Rating: 4A
  • Lead Content: Contains Lead
  • Glow Wire Compliant: No
  • Supply and Demand: Short
