15-24-7181 Real Image
Same model may have multiple batches, images only for reference.

15-24-7181

Part No 15-24-7181
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Multilock Connector Tab 18 POS 3.5mm Solder RA Thru-Hole Automotive Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Receptacle, Socket
Contact Material Brass
Contact Plating Tin
Country of Origin US
Current Rating 9 A
Depth 9.6 mm
Gender Female
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Nylon
Length 34 mm
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 600 V
Max Voltage Rating (DC) 600.6 kV
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 18
Number of Contacts 18
Number of Ports 1
Number of Positions 18
Number of Rows 2
Number of Terminals 18
Orientation Vertical
Pitch 4.2 mm
Radiation Hardening No
RoHS Compliant
Row Spacing 4.191 mm
Termination Solder
Voltage Rating (AC) 600 V
Win Source Part Number 1041215-15-24-7181
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 15-24-7181 CAD Model

Description

The Molex 15-24-7181 is a circular connector housing with 18 positions and a 4.2 mm pitch.

  • Positions: 18
  • Pitch: 4.2 mm
  • Connector Type: Female Receptacle and Socket
  • Housing Material: Nylon
  • Contact Plating: Tin
