TCM1-83X+ Real Image TCM1-83X+ real image TCM1-83X+ real image14098 TCM1-83X+ Real Image1 TCM1-83X+ Real Image2
Same model may have multiple batches, images only for reference.
TCM1-83X+ Real Image TCM1-83X+ real image TCM1-83X+ real image14098 TCM1-83X+ Real Image1 TCM1-83X+ Real Image2
TCM1-83X+ Real Image TCM1-83X+ real image TCM1-83X+ real image14098 TCM1-83X+ Real Image1 TCM1-83X+ Real Image2
Same model may have multiple batches, images only for reference.

TCM1-83X+

Part No TCM1-83X+
Manufacturer Mini-Circuits
Catalog Balun
Description 1:1 CORE & WIRE TRANSFORMER, 10
Datasheet
TCM1-83X+ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - Balun
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Frequency Range 10MHz ~ 8GHz
Impedance - Unbalanced/Balanced 50 / 50Ohm
Phase Difference 8°
Insertion Loss (Max) 3dB
Return Loss (Min) 10.56dB
Package / Case 6-SMD Module
Mounting Type Surface Mount
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.31.4035
Win Source Part Number 712482-TCM1-83X+
Ultra Librarian 3D Model Ultra Librarian TCM1-83X+ CAD Model

Description

The 712482-TCM1-83X+ is an RF and wireless balun designed for a frequency range of 10MHz to 8GHz. It has an impedance of 50/50 Ohm and a phase difference of 8 degrees.

  • Impedance: 50/50 Ohm
  • Phase Difference: 8 degrees
  • Insertion Loss: Maximum 3dB
  • Return Loss: Minimum 10.56dB
  • Mounting: Surface mountable
  • Package: 6-SMD module
  • Series: Mini-Circuits
  • Package Type: Tape and reel
  • Quantity: 2,000 pieces
  • MSL Level: 1 (Unlimited)
  • HTSUS Code: 8504.31.4035
  • Manufacturer: Mini-Circuits
  • Status: Active
