Microchip Technology USB2513B-AEZC-TR USB 2.0 Hi-Speed Hub Controller

The USB2513B-AEZC-TR is a versatile and powerful USB 2.0 Hi-Speed hub controller from Microchip Technology, designed to provide an efficient solution for expanding USB capabilities in various electronic devices. This highly integrated IC is part of Microchip's portfolio of USB hub controllers and is aimed at bridging the gap between downstream USB ports and upstream host connections.

Key Features:

• Multi-TT Architecture: The device supports multiple Transaction Translators (Multi-TT), which enables optimal bandwidth allocation for each downstream port, ensuring high throughput for USB Full-Speed and Low-Speed devices.
• PortMap and PortSwap: These features provide customizable port mapping and pin configuration, allowing for design flexibility and ease of PCB layout.
• Hi-Speed USB Compliance: With support for data transfer rates of up to 480 Mbps, the USB2513B-AEZC-TR is fully compliant with the USB 2.0 specification, ensuring compatibility with a wide range of USB devices.
• Automatic Link Power Management (ALPM): This power-saving feature helps reduce power consumption when the USB link is in a low-power state, contributing to energy-efficient designs.
• Configurability: The hub controller can be configured via pin strapping, I2C, or EEPROM, offering flexibility for various application requirements.
• Integrated ESD Protection: The device includes built-in electrostatic discharge (ESD) protection circuits, providing robustness and enhancing the durability of end products.

Applications:

The USB2513B-AEZC-TR is suitable for a broad spectrum of applications, including desktop and notebook PCs, docking stations, monitors, standalone USB hubs, and multimedia devices. Its compact design, coupled with advanced features, makes it an ideal choice for expanding USB connectivity in consumer, industrial, and automotive markets.

Offered in a 36-pin QFN package, the USB2513B-AEZC-TR is available in tape and reel packaging (TR suffix), facilitating efficient handling and manufacturing processes. Its operational temperature range and robust design ensure reliable performance across various environmental conditions.

With the USB2513B-AEZC-TR, Microchip Technology provides designers with a high-performance, easy-to-integrate USB hub solution that enhances the user experience by delivering seamless connectivity and advanced functionality.
