PIC18F2680-I/SO

Part No PIC18F2680-I/SO
Manufacturer Microchip Technology
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 64KB FLASH 28SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Core Processor PIC
Part Core Size 8-Bit
Speed(Frequency) 40MHz
Number of I/O 25
Program Memory Size 64KB (32K x 16)
Program Memory Type FLASH
EEPROM Size 1K x 8
Data RAM Size 3.25K x 8
Supply Voltage - Operating 4.2 V to 5.5 V
Data Converters A/D 8x10b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 28-SOIC
Win Source Part Number 061889-PIC18F2680-I/SO
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PIC18F2680-I/SO CAD Model

Description

Microchip Technology's PIC18F2680-I/SO Microcontroller

The PIC18F2680-I/SO from Microchip Technology is a high-performance microcontroller that belongs to the popular PIC18F series, known for its advanced RISC architecture. This particular model is designed to cater to a wide range of applications, from automotive systems to industrial control and consumer electronics.

The PIC18F2680-I/SO is housed in a compact SOIC (Small Outline Integrated Circuit) package, making it suitable for space-constrained applications. The microcontroller operates with an enhanced flash memory of 64KB, providing ample space for complex programs and data storage. Its 10-bit, 13-channel Analog-to-Digital Converter (ADC) ensures precise analog signal conversion, which is crucial for sensor-based applications.

With a 32KB RAM, the PIC18F2680-I/SO offers sufficient temporary data storage for multitasking environments and real-time processing needs. The device also features a rich set of peripherals, including two Enhanced Capture/Compare/PWM (ECCP) modules, which enable the generation of complex pulse widths and waveforms for motor control and other PWM applications.

Connectivity is a strong suit of the PIC18F2680-I/SO, offering both CAN (Controller Area Network) and USART (Universal Synchronous Asynchronous Receiver Transmitter) interfaces. The CAN interface is essential for automotive and industrial networks, allowing for robust and reliable communication in harsh environments. The USART interface facilitates serial communication, which can be used for interfacing with sensors, modems, or other microcontrollers.

Security features are also embedded within the microcontroller, including a Watchdog Timer (WDT) to prevent system lock-ups and a brown-out reset (BOR) to ensure proper operation during power fluctuations. Additionally, the device includes programmable Low Voltage Detect (LVD) to safeguard against low voltage conditions that could otherwise lead to unpredictable behavior.

Overall, the PIC18F2680-I/SO microcontroller is a versatile and powerful component that offers a balance of performance, power efficiency, and advanced features, making it an ideal choice for designers looking to develop robust and sophisticated electronic systems.
