Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Core Processor PIC
Part Core Size 8-Bit
Speed(Frequency) 20MHz
Number of I/O 5
Program Memory Size 1.75KB (1K x 14)
Program Memory Type FLASH
Data RAM Size 64 x 8
Supply Voltage - Operating 2 V to 5.5 V
Data Converters A/D 4x10b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 8-SOIC
Win Source Part Number 092529-PIC12F615-I/SN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name PIC12F615
Introduction Date January 16, 2006
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Not Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian PIC12F615-I/SN CAD Model

Description

Microchip Technology's PIC12F615-I/SN Microcontroller

The PIC12F615-I/SN is a high-performance microcontroller unit (MCU) from Microchip Technology, designed to cater to a wide range of applications requiring a compact, yet powerful and versatile microcontroller. This MCU is part of Microchip's renowned PIC12 family, known for their small form factor and low power consumption, making them ideal for space-constrained and power-sensitive applications.

With an 8-bit architecture, the PIC12F615-I/SN provides a perfect balance between performance and power efficiency. It operates at a voltage range of 2.0V to 5.5V, which allows for flexibility in different power environments and battery-operated applications. The MCU comes in an 8-pin SOIC package, which is not only space-saving but also easy to integrate into various PCB designs.

The PIC12F615-I/SN is equipped with 1.75KB of flash program memory, ensuring ample space for application code. It also features 64 bytes of EEPROM and 128 bytes of RAM, which are essential for data storage and efficient memory management during operation. Its clock speed can go up to 20 MHz, providing sufficient processing power for a myriad of tasks.

This MCU includes an array of integrated peripherals that enhance its functionality and reduce the need for additional components. Some of these peripherals include an Analog-to-Digital Converter (ADC) with up to 4 channels, a comparator, and a Pulse Width Modulation (PWM) module. These features make it particularly suitable for applications such as LED lighting control, battery management, and small motor control.

For developers, the PIC12F615-I/SN supports in-circuit serial programming (ICSP) for convenient programming and debugging. Additionally, it is compatible with Microchip's MPLAB® development environment, providing access to a comprehensive suite of development tools to streamline the design process.

In summary, the PIC12F615-I/SN from Microchip Technology is a robust, versatile, and easy-to-use microcontroller that offers a powerful set of features in a small package. Whether for industrial, consumer, automotive, or any other low-power application, this MCU is an excellent choice for designers looking to maximize functionality while minimizing space and power consumption.
