Microchip Technology MCP6004T-E/ST Operational Amplifier

The MCP6004T-E/ST is a high-performance operational amplifier (op-amp) designed by Microchip Technology, a leading provider of microcontroller, mixed-signal, analog, and Flash-IP solutions. This op-amp is part of Microchip's MCP6004 family of low-power, general-purpose operational amplifiers that are popular for a wide range of applications due to their robust features and cost-effectiveness.

Key Features:

• Quad Operational Amplifiers: The MCP6004T-E/ST contains four independent op-amps in a single package, offering design flexibility and space-saving advantages.
• Low Power Consumption: With a quiescent current of just 100 µA (typical) per amplifier, this device is optimized for battery-powered and portable applications.
• Wide Supply Voltage Range: It can operate from a single supply voltage as low as 1.8V to as high as 6.0V, making it versatile for both single and dual supply operations.
• Rail-to-Rail Input/Output: The op-amps feature rail-to-rail input and output swing, which extends the dynamic range and is ideal for driving analog-to-digital converters (ADCs).
• Extended Temperature Range: This device is capable of operating in extended temperature ranges from -40°C to +125°C, suitable for industrial environments.
• Gain Bandwidth Product: It offers a gain bandwidth product of 1 MHz (typical), which is adequate for low frequency applications such as sensor interfacing, A/D convertor driving, and audio processing.

Applications:

The MCP6004T-E/ST is ideal for a range of applications, including:

• Portable Equipment
• Battery-Powered Devices
• Analog Filters
• Data Acquisition
• Signal Conditioning
• Audio Amplification

Package and Quality:

The MCP6004T-E/ST comes in a 14-pin TSSOP (Thin Shrink Small Outline Package), which offers a compact footprint for space-constrained applications. Microchip Technology is committed to high-quality standards and ensures that their products meet stringent reliability testing. This op-amp is RoHS compliant and lead-free, making it suitable for use in environmentally sensitive applications.
