Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Features - Motor Driver Power MOSFET LIN 48-VQFN (7x7)
Manufacturer Microchip Technology
Package Reel - TR
Part Status Obsolete
Operating Temperature Range -40°C ~ 150°C (TA)
Mounting Surface Mount
Package 48-VFQFN Exposed Pad
Case / Package 48-VQFN (7x7)
Family Name ATA6843
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number ATA6843-PLQW-ND, ATA6843-PLQWTR, ATA6843PLQW, ATA6843-PLQWDKR, ATA6843-PLQWCT
Quantity per package 4000
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 862284-ATA6843-PLQW
Ultra Librarian 3D Model Ultra Librarian ATA6843-PLQW CAD Model

Description

The ATA6843-PLQW is a cutting-edge motor controller from Microchip Technology, designed to bring high efficiency and reliability to automotive applications. This sophisticated piece of technology is tailored to meet the stringent requirements of modern vehicle designs, particularly those involving brushless DC motors.

Key Features

  • High Integration: The ATA6843-PLQW integrates a six-channel half-bridge driver with a voltage regulator and LIN transceiver, making it a compact solution for motor control.
  • Wide Voltage Range: Operating from a supply voltage of 5.5V up to 28V, this device is versatile and can handle the electrical environments typical in automotive applications.
  • Protected Outputs: Each of the six high-side and low-side drivers is protected against overcurrent, providing robustness and enhancing the longevity of the motor controller.
  • Thermal Management: The device includes over-temperature protection, ensuring reliable operation under varying temperature conditions.
  • Communication Interface: With an integrated LIN transceiver, the ATA6843-PLQW supports local interconnect network communication, facilitating easy integration into automotive networks.

Applications

The ATA6843-PLQW is primarily suited for automotive environments, where it can be used to control various types of motors. Applications include, but are not limited to:

  • Automotive HVAC systems
  • Engine cooling fans
  • Fuel pumps
  • Active grille shutters
  • Other automotive mechatronic systems requiring precise motor control

Quality and Reliability

Microchip Technology is known for its commitment to quality, and the ATA6843-PLQW is no exception. It is designed to meet the rigorous standards of the automotive industry, ensuring high reliability and performance even under the most demanding conditions. This motor controller is an essential component for automotive engineers looking to enhance the efficiency and effectiveness of their motor-driven systems.

For more information about the ATA6843-PLQW, including detailed specifications, application notes, and support resources, visit the Microchip Technology website.
