The 1N758 from Microchip Technology is a precision Zener diode designed to offer a reliable voltage reference with a nominal voltage of 10V. This diode is a member of the 1N75x series, which are well-known for their stability and consistency in performance. The 1N758 is widely used in various electronic applications such as voltage regulation, surge suppression, and voltage reference circuits.

Key Features

• Nominal Zener Voltage: 10V with a standard tolerance of ±5%.
• Power Dissipation: Capable of dissipating up to 400 mW, making it suitable for a range of power applications.
• Temperature Stability: Exhibits excellent stability across a wide temperature range, ensuring reliable operation under varying environmental conditions.
• Package Type: Available in a DO-35 glass package, which offers both durability and compactness for design flexibility.
• Test Current: The Zener test current (I_ZT) is specified at 20 mA, providing a standard for performance evaluation and comparison.

Applications

The 1N758 Zener diode is versatile and can be utilized in numerous electronic circuits. Some common applications include:

• Voltage regulation in power supplies to ensure stable output voltage.
• Protection circuits where it can clamp transient overvoltages and protect sensitive components.
• Precision reference voltage sources in analog-to-digital converters, digital-to-analog converters, and other precision circuitry.
• Waveform shaping circuits where it can be used to clip or stabilize signals.

Quality and Reliability

Microchip Technology is renowned for its commitment to quality, and the 1N758 Zener diode is no exception. Each diode is rigorously tested to ensure it meets the high standards expected by industry professionals. With its robust construction and reliable performance, the 1N758 is an excellent choice for designers looking for a dependable voltage reference solution.
