GS1M-LTP Real Image GS1M-LTP real image4501
Same model may have multiple batches, images only for reference.
GS1M-LTP Real Image GS1M-LTP real image4501
GS1M-LTP Real Image GS1M-LTP real image4501
Same model may have multiple batches, images only for reference.

GS1M-LTP

Part No GS1M-LTP
Manufacturer Micro Commercial Co
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 1KV 1A DO214AC
Datasheet
GS1M-LTP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1000V (1kV)
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1V @ 1A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 10μA @ 1000V
Capacitance @ Vr, F 15pF @ 4V, 1MHz
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 132372-GS1M-LTP
Popularity Medium
Supply and Demand Status Limited
Quantity per package 7,500
Ultra Librarian 3D Model Ultra Librarian GS1M-LTP CAD Model

Description

The Micro Commercial Co GS1M-LTP is a standard diode with the following specifications:

  • Voltage Peak Reverse: 1000V
  • Average Rectified Current: 1A
  • Forward Voltage: 1V @ 1A
  • Reverse Leakage Current: 10μA @ 1000V
  • Package: DO-214AC (SMA)
  • Operating Temperature: -55°C to 150°C

The diode is ideal for use in discrete semiconductor products.
