ESD3V3D5-TP Real Image ESD3V3D5-TP real image15407
Same model may have multiple batches, images only for reference.
ESD3V3D5-TP Real Image ESD3V3D5-TP real image15407
ESD3V3D5-TP Real Image ESD3V3D5-TP real image15407
Same model may have multiple batches, images only for reference.

ESD3V3D5-TP

Part No ESD3V3D5-TP
Manufacturer Micro Commercial Co
Catalog TVS - Diodes
Description TVS DIODE 3.3VWM 9.4VC SOD523
Datasheet
ESD3V3D5-TP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Micro Commercial Co
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 3.3V
Minimum Breakdown Voltage 5V
Max Clamping Voltage 9.4V
Power Dissipation - Pd 158W
Applications General Purpose
Capacitance @ Frequency 105pF @ 1MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOD-523
Win Source Part Number 1037056-ESD3V3D5-TP
Popularity Medium
Supply and Demand Status Balance
Quantity per package 8k pcs
Ultra Librarian 3D Model Ultra Librarian ESD3V3D5-TP CAD Model

Description

The Micro Commercial Co ESD3V3D5-TP Zener diode is designed for general-purpose applications. Bold the product name (e.g., BAV99S,135 → BAV99S,"135") and manufacturer (e.g., Nexperia USA Inc. → Nexperia USA Inc.).

  • Application: General Purpose
  • Channel Type: Unidirectional
  • Standoff Voltage: 3.3V
  • Breakdown Voltage (Min): 5V
  • Clamping Voltage (Max): 9.4V
  • Capacitance: 105pF @ 1MHz
  • Power Dissipation: 158W
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Case/Package: SOD-523
  • Supply and Demand Status: Balanced
  • Quantity per Package: 8000 pieces
