The BAS40DW-05-TP is a Schottky barrier diode array from Micro Commercial Co. It is designed for applications requiring fast switching speeds and low forward voltage drop. This diode array consists of two Schottky diodes connected in series, offering enhanced performance in various electronic circuits.

Applications

• High-speed switching circuits
• Protection circuits
• Clamping circuits
• Reverse polarity protection
• DC-DC converters

Features

• Low forward voltage drop
• Fast switching speed
• Surface mount package
• High surge current capability
• RoHS compliant

Benefits

• Improved efficiency in switching applications due to low forward voltage drop.
• Effective protection against voltage transients and reverse polarity.
• Compact design suitable for space-constrained applications.
• Reliable performance under high surge conditions.
• Environmentally friendly due to RoHS compliance.

Additional Details

The BAS40DW-05-TP has a maximum repetitive reverse voltage of 40V and a forward current of 200mA per diode. The operating temperature range typically spans from -55°C to +125°C. The device is available in a SOT-323 package for easy surface mounting. The low forward voltage drop (typically 0.35V at 10mA) minimizes power loss in the circuit. The fast reverse recovery time ensures efficient operation in high-frequency applications. The device is commonly used in portable devices, communication equipment, and industrial applications where space and performance are critical.

The BAS40DW-05-TP is a reliable and efficient solution for a variety of diode array applications, offering a combination of fast switching, low forward voltage drop, and robust protection capabilities.
