MMC3140MS Memsic Inc.
Same model may have multiple batches, images only for reference.

MMC3140MS

Part No MMC3140MS
Manufacturer Memsic Inc.
Catalog Magnetic Sensors - Linear, Compass (ICs)
Description MAGNETIC SENSOR 3-AXIS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Magnetic Sensors - Linear, Compass (ICs)
Mfr Memsic Inc.
Package Tape & Reel
Product Status Obsolete
Technology Magnetoresistive
Axis X, Y, Z
Output Type I2C
Sensing Range ±0.4mT
Voltage - Supply 2.7V ~ 5.25V
Current - Supply (Max) 550µA
Bandwidth 25Hz
Temperature Range - Operating -40°C ~ 85°C
Features Temperature Compensated
Supplier Device Package 10-LGA (3.05x3.05)
Mounting Type Surface Mount
Package / Case 10-TFLGA Exposed Pad
Standard Package 3,000 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN OBSOLETE
Win Source Part Number 831198-MMC3140MS
Ultra Librarian 3D Model Ultra Librarian MMC3140MS CAD Model

Description

The MMC3140MS is a magnetic sensor from Memsic Inc.

  • Voltage Supply: 2.7V to 5.25V
  • Operating Temperature: -40°C to 85°C
  • Output: I2C
  • Bandwidth: 25Hz
  • Current Supply: 550µA
  • Sensing Range: ±0.4mT
  • Package: Tape & reel
  • Standard Package Size: 3,000 pcs
  • Axes: Tri-axis (X, Y, Z)
